The double automatic sliding door uses good material and advanced technology,has good sealing andinsulation performance,and has long working life.The safety release parts allow the door to be opened from inside.
Application industry
Food, industrial, supermarket, storage, pharmaceutical, retail
Applicable environment
Cold chain logistics warehouse, large cold storage
Optional Accessories
The anti-collision pillar is installed on the inside of the door opening to prevent transport vehicles from accidentally hitting the door body.
Sealing strip
Made with EPDM, it has good chemical stability, durability, and excellent aging performance
Different, with wide temperature adaptability, the long-term working temperature is -50 ºC~+130 ºC.
Door panel
Polyurethane is used to foam the panel as a whole, with a smooth appearance and good insulation performance. For extra large doors, small panels can be foamed first, and the door panels can be spliced on site. Appropriate measures are taken to cut off the cold bridge by wrapping the edges, ensuring the performance and requirements of use.
Door frame
Made of colored steel plate foam door frame, aluminum alloy or C-shaped steel with stainless steel foam on theoutside,Neat and elegant, durable, overcoming the low strength and easy decay of wooden door frames
Disadvantages of. And equipped with a self limiting temperature electric heating strip, without the need for temperature control or manual power on/off.
Guide rail device
The aluminum alloy guide rail is made of guide wheels and clamping wheel devices that move together inside,
Separate the door from the frame when it opens and press it tightly against the floor of the frame when it closes.
Drive system
Adopting worm gear and worm gear reduction, synchronous belt transmission of motion, and equipped with electromagnetic clutch
The device automatically switches between electric and manual modes, ensuring the safety and practicality of the electric door usability
Electronic control system
Famous nameplate electrical components ensure the reliability and durability of the electrical control system,The PLC programmable controller greatly simplifies the circuit of the electrical control system, and only requires external components ,Some switch signal components are connected to the PLC, which collects signals from each switch Perform centralized processing, program design various triggering states corresponding to different response situations .Moreover, it can achieve delayed automatic door closing and automatic judgment of when to start the delay function,to achieve perfect control of the door.
